Description
Key Features:-
– 3x 1/2.8” 2MP progressive scan Exmor R CMOS
– Support H.265 & H.264 dual encoding
– Smart triple streams supported
– Max 25fps @ 4096 x 832
– Support 180-degree panoramic view
– Day/Night(ICR), 3DNR, AWB, AGC, BLC, WDR
– Smart detection
– Intelligent Function
– Max. IR LEDs length 30m
– IP67, IK10, PoE
Specification
| mage Sensor | Three 1/2.8” 2Megapixel Exmor R CMOS |
| Effective Pixels | 4096(H)x832(V) |
| RAM/ROM | 1024MB/128MB |
| Scanning System | Progressive |
| Minimum Illumination | 0.007Lux/F1.8( Color), 0Lux/F1.8(IR on) |
| S/N Ratio | More than 50dB |
| IR Distance | Distance up to 30m(98ft) |
| IR On/Off Control | Auto/ Manual |
| IR LEDs | 8 |
| Lens | |
| Lens Type | Fixed |
| Mount Type | Board-in |
| Focal Length | 3.6mm |
| Max. Aperture | F1.8 |
| Angle of View | H: 180˚, V:44˚ |
| Optical Zoom | N/A |
| Focus Control | Fixed |
| Close Focus Distance | N/A |
| Pan/Tilt/Rotation | |
| Pan/Tilt/Rotation Range | Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚ |
| Intelligence | |
| IVS (optional) | Tripwire, Intrusion, Object Abandoned/Missing |
| Advanced Intelligent Functions | Face Detection, People Counting, Heat Map, E-PTZ |
| Video | |
| Compression | H.265/H.264 |
| Streaming Capability | 3 Streams |
| Resolution | 4096×832/3840×780/2560×520/1280×260/1024X208 |
| Frame Rate | Main Stream: 4096×832(1~25/30fps) |
| Sub Stream: 1024X208 (1 ~ 25/30fps) | |
| Third Stream: 1280×260 (1 ~ 25/30fps) | |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.265: 4Kbps~ 10MbpsH.264: 8Kbps~ 16Mbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC Mode | BLC / HLC / WDR(120dB) |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detetion | Off / On (4 Zone, Rectangle) |
| Region of Interest | Off / On (4 Zone) |
| Electronic Image Stabilization(EIS) | N/A |
| Smart IR | Support |
| Defog | N/A |
| Digital Zoom | 16x |
| Flip | N/A |
| Mirror | N/A |
| Privacy Masking | Off / On (4 Area, Rectangle) |
| Audio | |
| Compression | G.711a/G.711Mu/AAC/ G.726 |
| Network | |
| Ethernet | RJ-45 (100/1000Base-T) |
| Protocol | HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP;DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP; NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP |
| Interoperability | ONVIF, PSIA, CGI |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 10 Users/20 Users |
| Edge Storage | NASLocal PC for instant recording Mirco SD card 128GB |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | Smart PSS, DSS, Easy4ip |
| Smart Phone | IOS, Android |
| Certifications | |
| Certifications | CE (EN 60950:2000)UL:UL60950-1 FCC: FCC Part 15 Subpart B |
| Interface | |
| Video Interface | N/A |
| Audio Interface | 1/1 channel In/Out |
| RS485 | N/A |
| Alarm | 2/1 channel In/Out |
| Electrical | |
| Power Supply | AC24V, PoE (802.3at)(Class 4) |
| Power Consumption | <23W |
| Environmental | |
| Operating Conditions | -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH |
| Strorage Conditions | -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH |
| Ingress Protection | IP67 |
| Vandal Resistance | IK10 |
| Construction | |
| Casing | Metal |
| Dimensions | 298.3mm×172.5mm×120.5mm(11.74”×6.79”×4.74”) |
| Net Weight | 2.60kg(5.73lb) |
| Gross Weight | 3.41 kg(7.52lb) |
